花崗石平台、花崗岩平台 (量測檢驗平台)
 |
|
花崗石物理性質 |
| 美規平台 | A級 | 重量kg |
|
規 格 mm 長×寬×厚 |
平面度 um | |
| 450X300X75 | 3.1 | 30.4 |
| 450X450X75 | 3.3 | 45.6 |
| 600X450X100 | 3.6 | 81.0 |
| 600X600X100 | 3.8 | 108.0 |
| 900X600X130 | 4.3 | 210.6 |
| 1200X900X150 | 5.5 | 486.0 |
| 1500X1500X200 | 6.5 | 1350.0 |
|
|
||
| 歐規平台 | 00級 | 重量kg |
| 規 格 mm 長×寬×厚 |
平面度 um | |
| 150X150X50 | 2.4 | 3.4 |
| 200X150X50 | 2.5 | 4.5 |
| 250X200X50 | 2.6 | 7.5 |
| 300X200X50 | 2.7 | 9.0 |
| 300X300X60 | 2.9 | 16.2 |
| 400X400X75 | 3.1 | 36.0 |
| 630X400X100 | 3.6 | 75.6 |
| 630X630X100 | 3.9 | 119.1 |
| 800X500X130 | 4.0 | 156.0 |
| 1000X630X150 | 4.5 | 283.5 |
| 1000X750X150 | 4.6 | 337.5 |
| 1000X1000X150 | 5.0 | 450.0 |
| 1500X1000X200 | 6.0 | 900.0 |
| 2000X1000X200 | 7.0 | 1200.0 |
| 2000X1500X200 | 7.5 | 1800.0 |
|
|
||
